| Balanced microphone inputs with XLR connectors | ✖ |
| Balanced line inputs with ¼ "TRS connectors (P10) | ✖ |
| Line inputs with ¼ "TRS connectors (P10) | ✖ |
| Line inputs with RCA connectors | ✖ |
| Outputs with ¼ "TRS connectors (P10) | ✖ |
| RCA Output | ✖ |
| Resposta em frequência @-3dB: | 1Hz ~ 75Khz |
| Total Harmonic Distortion | <0,01% (T.H.D.) |
| Signal to Noise | 110dB |
| LINE input sensitivity, Channels 1 and 2 (Gain Pos.) | Line (P10/RCA) Min: 1,9V ~ Max: 45mV |
| Equalization bands per channel | Low ±15dB (80Hz) | Mid Low ±15dB (500Hz) |Mid High ±15dB (3K5Hz) | High ±15dB (12KHz) |
| Impedance of the inputs of channels 1 and 2 | Line (P10): Desbalanceada 95KOhms | Line (RCA): Desbalanceada 95KOhms |
| Impedance Output | Main Out (P10/RCA): 47R | Aux Out (P10/RCA): 47R |
| Maximum level of outputs | Main Out (P10/RCA): 16 dBu/4,9Vac | Aux Out (P10/RCA): 16 dBu/4,9Vac |
| Supply Voltage | 9 ~ 16 Vdc |
| Consumption Highest | 230 mA |
| Remote Input | 9 ~ 16 Vdc |
| Remote Output Maximum Current | 250 mA |
| Dimensions (H x W x D) mm | 46,5 x 132 x 199,5 |
| Weight Kg | 0,7 Kg |
